Stable Constantan 6J40 6J11 Wire for Industrial Sensor Applications

Our Stable Constantan 6J40 6J11 Wire is a high-performance material designed for industrial sensors, thermocouples, and precision resistors. With nickel contents of 40% (6J40) and 11% (6J11), these copper-nickel alloys offer exceptional resistivity, corrosion resistance, and thermal stability. They’re perfect for industries like aerospace, chemical processing, and industrial automation, where sensors need to perform flawlessly in tough conditions. Available in diameters from 0.01mm to 3mm, our wires are crafted with precision to meet the strictest standards, ensuring top-notch quality for your projects.

Constantan 6J40’s high resistivity (49 µΩ·cm at 20°C) makes it ideal for high-accuracy resistors and thermocouples in extreme environments, while 6J11’s lower resistivity (25 µΩ·cm) suits sensors requiring balanced performance. Both alloys offer excellent corrosion resistance and operate reliably up to 600°C (6J40) and 400°C (6J11). We’ve optimized our production process to deliver wires that are durable, consistent, and ready for the most demanding industrial applications.

For more details, pls directly contact us.

Constantan 6J40 and 6J11 are built for precision and durability. The 40% nickel in 6J40 provides high resistivity and exceptional stability, making it perfect for thermocouples and resistors in high-temperature environments like aerospace or industrial furnaces. Constantan 6J11, with 11% nickel, offers a lower resistivity for applications like sensors in chemical processing, where cost-efficiency and reliability are key. Compared to lower-nickel alloys like CuNi6 or CuNi8, both provide superior corrosion resistance and thermal stability.

Their thermal conductivity—23 W/mK (6J40) and 40 W/mK (6J11)—ensures efficient heat management, critical for sensors and thermocouples. With tensile strengths of 420 MPa (6J40) and 300 MPa (6J11), they’re tough enough to handle mechanical stress. Their low temperature coefficient of resistance (TCR) keeps electrical properties stable across wide temperature ranges, from -200°C to 600°C (6J40) or 400°C (6J11). Their excellent corrosion resistance makes them ideal for harsh environments, like chemical plants or marine settings, ensuring long-term sensor reliability.

Parameter:

Properties Material	Resistivity 200c μΩ.m	Max working temperature (℃)	Tensile strength (Mpa)	Melting point (℃）	Density (g/cm3)	TCR *10-6/℃ (20-600℃）	EMF vs Cu (μV/℃） （0-100℃）
CuNi1	0.03	200	210	1085	8.9	＜100	-8
CuNi2	0.05	200	220	1090	8.9	＜120	-12
CuNi6	0.1	220	250	1095	8.9	＜60	-18
CuNi8	0.12	250	270	1097	8.9	＜57	-22
CuNi10	0.15	250	290	1100	8.9	＜50	-25
CuNi14	0.2	300	310	1115	8.9	＜30	-28
CuNi19	0.25	300	340	1135	8.9	＜25	-32
CuNi23	0.3	300	350	1150	8.9	＜16	-34
CuNi30	0.35	350	400	1170	8.9	＜10	-37
CuNi34	0.4	350	400	1180	8.9	0	-39
CuNi44	0.5	400	420	1200	8.9	＜-6	-43

Size Range
Wire	0.08-7.5mm
Ribbon	(0.05-0.35)*(0.5-6.0)mm
Strip	(0.50-2.5)*(5-180)mm
Rod	8-50mm

For more details, pls directly contact us.

The copper-nickel alloy market is thriving, driven by demand for high-performance materials in aerospace, chemical processing, and industrial automation. Industrial sensors are seeing increased adoption as companies embrace IoT, smart manufacturing, and real-time monitoring. The global sensor market is projected to grow at a CAGR of around 6.7% through 2030, fueled by advancements in aerospace, electric vehicles (EVs), and renewable energy systems.

Constantan 6J40 and 6J11 wires are well-positioned in this landscape. Their high resistivity and corrosion resistance make them ideal for sensors and thermocouples in demanding environments, like aerospace control systems or chemical processing plants. The rise of EVs and renewable energy, such as wind and solar, is boosting demand for durable alloys that can handle high temperatures and corrosive conditions. Meanwhile, the push for precision in smart manufacturing is driving the need for reliable sensor materials, where these alloys shine.

Sustainability is a major trend shaping the industry. Companies are seeking eco-friendly materials to meet environmental regulations, and our Constantan 6J40 and 6J11 wires deliver. Produced with energy-efficient processes, they’re fully recyclable, helping you achieve green goals without sacrificing performance. The trend toward miniaturization in electronics is another driver, with industries demanding thinner wires for compact sensor designs. Our ability to produce wires as fine as 0.01mm keeps us ahead of the curve.

Emerging technologies, like IoT-enabled sensors and advanced control systems, are increasing the demand for high-precision alloys. These systems require materials that maintain accuracy in harsh conditions, and Constantan 6J40 and 6J11 are up to the task. As industries continue to innovate, the demand for high-performance alloys like these will keep growing.

Applications of Constantan 6J40 and 6J11 Wire

Our Constantan 6J40 and 6J11 wires are versatile materials with a wide range of applications. Here’s where they make an impact:

• Industrial Sensors: Their corrosion resistance and stable electrical properties make them ideal for temperature and pressure sensors in chemical processing, marine, and automation systems.

• Thermocouples: 6J40 is perfect for Type T, J, and E thermocouples in aerospace and industrial furnaces, while 6J11 suits Type T and J in medium-temperature applications.

• High-Accuracy Resistors: 6J40’s high resistivity is ideal for precision resistors in electronics and automotive systems; 6J11 supports cost-effective resistor applications.

• Aerospace Applications: Used in sensors and control systems for aircraft and spacecraft, they ensure reliability in high-temperature, corrosive environments.

• Chemical Processing: Their resistance to harsh chemicals makes them suitable for sensors and components in chemical plants.

• Renewable Energy: In wind and solar systems, they’re used in sensors that require durability in outdoor, corrosive conditions.

Their flexibility also makes them suitable for custom applications, like precision circuit breakers and conductive elements, where reliability and accuracy are critical.

Comparison Table: Constantan 6J40 vs. Constantan 6J11 vs. CuNi6 vs. CuNi8

Property	Constantan 6J40	Constantan 6J11	CuNi6	CuNi8
Nickel Content (%)	40	11	6	8
Resistivity at 20°C (µΩ·cm)	49	25	15	20
Max Operating Temp (°C)	600	400	300	350
Thermal Conductivity (W/mK)	23	40	50	45
Tensile Strength (MPa)	420	300	250	260
Corrosion Resistance	Excellent	Very Good	Good	Very Good
Applications	Thermocouples, resistors, sensors	Sensors, resistors	Thermocouples, resistors	Sensors, resistors
Thermocouple Types	T, J, E	T, J	T, J	T, J

We’re not just a supplier—we’re a leader in delivering high-quality Constantan 6J40 and 6J11 Wire. Here’s why we stand out:

• Precision Manufacturing: Our advanced processes produce wires with tight tolerances, from 0.01mm to 3mm in diameter, ensuring consistent performance for your applications.

• Custom Solutions: We offer fully customizable wire sizes and configurations to meet your specific needs, whether for sensors, thermocouples, or resistors.

• Rigorous Quality Control: Every batch undergoes extensive testing in our state-of-the-art labs, meeting ASTM and ISO9001 standards for chemical and physical properties.

• Global Expertise, Local Support: With over 40 years of experience, we export to more than 70 countries and provide dedicated support to ensure your projects succeed.

• Eco-Friendly Production: Our energy-efficient processes and recyclable materials help you meet sustainability goals without sacrificing quality.

• Fast Delivery: Our streamlined production and logistics ensure quick turnaround times, even for custom orders, keeping your projects on schedule.

Compared to others, our focus on precision, customization, and sustainability gives us a clear advantage. We deliver products tailored to your needs and built to perform in demanding industrial environments.

Looking Forward

The future of Constantan 6J40 and 6J11 Wire is promising. As industries like aerospace, chemical processing, and renewable energy continue to grow, the demand for high-precision, corrosion-resistant alloys will soar. We’re committed to staying ahead, investing in R&D to enhance our wires’ properties and meet emerging challenges. From developing finer wires for compact sensors to improving corrosion resistance for next-generation applications, we’re always innovating.

Our Constantan 6J40 and 6J11 wires are critical components in the systems driving modern industries. From sensors in chemical plants to thermocouples in aerospace systems, they’re small but essential parts of the bigger picture. We’re excited to support our customers in building reliable, sustainable solutions for the future.

For more details, pls directly contact us.

About Us:

Our 12,000㎡ factory is equipped with complete capabilities for research, production, testing, and packaging. We strictly adhere to ISO 9001 standards in our production processes, with an annual output of 1,200 tons. This ensures that we meet both quantity and quality demands. Furthermore, all products undergo rigorous simulated environment testing including high temperature, high pressure, and corrosion tests before being dispatched, ensuring they meet customer specifications.

For all our clients, we offer timely and multilingual after-sales support and technical consulting, helping you resolve any issues swiftly and efficiently.

Client Visits

Building Stronger Partnerships

We support all kinds of testing:

FAQs：

1. What is Stable Constantan 6J40 6J11 Wire used for?
   It’s used for industrial sensors, thermocouples, and high-precision resistors in industries like aerospace, chemical processing, and automation.

2. Why are Constantan 6J40 and 6J11 ideal for industrial sensors?
   Their high resistivity and stable thermoelectric properties ensure accurate and reliable performance in harsh industrial environments.

3. Which industries rely on Constantan 6J40 and 6J11 Wire?
   Aerospace, chemical processing, automotive, renewable energy, and industrial automation use them for sensors and resistors.

4. How do Constantan 6J40 and 6J11 compare to other copper-nickel alloys?
   With 40% (6J40) and 11% (6J11) nickel, they offer higher resistivity and better corrosion resistance than CuNi6 or CuNi8.

5. What are the temperature limits for Constantan 6J40 and 6J11 Wire?
   6J40 operates from -200°C to 600°C; 6J11 up to 400°C, suitable for high and medium-temperature applications.

6. Are Constantan 6J40 and 6J11 resistant to corrosion?
   Yes, both provide excellent corrosion resistance, ideal for harsh environments like chemical plants or marine settings.

7. Can Constantan 6J40 and 6J11 Wire be customized for specific projects?
   We offer customizable wire diameters, from 0.01mm to 3mm, tailored to meet your project requirements.

8. What’s the lifespan of Constantan 6J40 and 6J11 in sensor applications?
   With proper use, they deliver consistent performance for years in demanding industrial conditions.
