Hastelloy C-276 Bar for Flue Gas Desulfurization Scrubber Supports

Our Hastelloy C-276 bar is a total beast for flue gas desulfurization scrubber supports, built to take on the nastiest corrosive environments in power plants and industrial facilities. This nickel-molybdenum-chromium alloy, with about 57% nickel, 16% molybdenum, 16% chromium, plus a touch of tungsten and iron, is our go-to for applications where corrosion resistance and strength are critical. Whether it’s structural rods, fasteners, or scrubber supports in desulfurization systems, this bar keeps your equipment standing strong and reliable.

For more details, pls directly contact us.

What makes Hastelloy C-276 bar stand out is its incredible ability to resist corrosion from sulfur compounds, acids, and chlorides, which are common in flue gas desulfurization processes. It’s perfect for scrubber supports, fighting off pitting, crevice corrosion, and stress corrosion cracking to ensure your systems stay robust with minimal maintenance. This bar helps you meet tough emission standards while keeping your operations running smoothly

Parameter	Hastelloy C-276 Bar	Hastelloy C-22 Bar	Stainless Steel 316 Bar	Monel 400 Bar
Corrosion Resistance	Excellent (sulfur compounds, acids)	Excellent, better in oxidizing acids	Good, weaker in chlorides	Excellent, less in sulfur settings
Thermal Conductivity	Low (~10 W/m·K)	Low (~10 W/m·K)	Low (~15 W/m·K)	Moderate (~22 W/m·K)
Thermal Stability	High (up to 1093°C)	High (up to 1038°C)	High (up to 870°C)	Moderate (up to 550°C)
Mechanical Strength	High, good ductility	High, slightly less ductile	Very high, less ductile	Good, high ductility
Formability	Moderate, requires special handling	Moderate, requires special handling	Moderate, harder to machine	Excellent, easy to machine
Cost	High, due to alloy complexity	High, similar to C-276	Moderate, lower than Hastelloy	High, lower than C-276
Typical Applications	Scrubber supports, reactor shafts	Marine components, chemical seals	Marine fittings, chemical components	Marine supports, desalination parts
Durability	Long lifespan, excellent in harsh settings	Long, slightly less in pitting	Long, varies in acidic environments	Very long, less in sulfur settings

This bar’s versatility is a huge win. It’s stable up to 1093°C, which is more than enough for scrubber systems operating in high-heat conditions, like those in coal-fired power plants or petrochemical facilities. Its low thermal conductivity (~10 W/m·K) helps with thermal management, and its high strength ensures it holds up under mechanical stress. From industrial smokestacks to cleaner energy systems, Hastelloy C-276 delivers.

We love how workable this bar is, even with its complex alloy makeup. You can machine, forge, or weld it into whatever your scrubber support design needs—think heavy-duty rods or sturdy fasteners. Need a specific diameter, length, or finish? We can tailor it to fit your specs, ensuring smooth fabrication and keeping your project on track.

The flue gas desulfurization industry’s all about materials that are tough, efficient, and sustainable, and Hastelloy C-276 bar checks every box. It’s recyclable, which is great for eco-friendly projects, and its long lifespan means less waste from replacements. With global regulations pushing for cleaner air and lower sulfur emissions—think decarbonization and green energy initiatives—demand for reliable materials like Hastelloy C-276 is soaring. Its low maintenance aligns with the trend toward cost-effective, sustainable solutions.

Specification

item	HC-276	C-22	C-4	B2	B3	N
C	≤0.01	≤0.015	≤0.015	≤0.02	≤0.01	0.04-0.08
Mn	≤1	≤0.5	≤1	≤1	≤3	≤1
Fe	4-7	2-6	≤3	≤2	≤1.5	≤5
P	≤0.04	≤0.02	≤0.04	≤0.04	--	≤0.015
S	≤0.03	≤0.02	≤0.03	≤0.03	--	≤0.02
Si	≤0.08	≤0.08	≤0.08	≤0.1	≤0.1	≤1
Ni	rest	rest	rest	rest	≤65	rest
Co	≤2.5	≤2.5	≤2	≤1	≤3	≤0.2
Ti+Cu	--	--	≤0.7	--	≤0.4	≤0.35
Al+Ti	--	--	--	--	≤0.5	≤0.5
Cr	14.5-16.5	20-22.5	14-18	≤1	≤1.5	6-8
Mo	15-17	12.5-14.5	14-17	26-30	≤28.5	15-18
B	--	--	--	--	--	≤0.01
W	3-4.5	2.5-3.5	--	--	≤3	≤0.5
V	≤0.35	≤0.35	--	0.2-0.4	--	≤0.5

Shape	Size (mm)
Wire	0.5-7.5
Rod/Bar	8.0-200
Strip	(0.5-2.5)*(5-180)
Tube/Pipe	Custom made
Sheet/Plate	Custom made

For more details, pls directly contact us.

Our Hastelloy C-276 bar sets the standard because we’re all about quality, customization, and customer success. We offer a wide range of diameters, lengths, and finishes, with fast delivery for both small and large orders. Our team dives into your project, optimizing the bar for your scrubber supports to ensure maximum corrosion resistance and durability. We keep pricing competitive, especially for bulk orders, without skimping on quality. Our sustainable production process uses recyclable materials, aligning with green industry trends. Plus, our hands-on support means you’re always covered—whether it’s technical guidance or a custom solution, we make it happen.

Compared to other materials, our Hastelloy C-276 bar is a standout. Hastelloy C-22 is great for oxidizing acids but slightly less effective in reducing acid and sulfur environments. Stainless steel 316 is tough but struggles with chlorides and sulfur compounds, unlike C-276. Monel 400 is corrosion-resistant but lacks C-276’s high-temperature stability and sulfur resistance. Our bar is the go-to for flue gas desulfurization scrubber supports.

We craft our Hastelloy C-276 bar to meet strict standards like ISO 9001, ensuring quality you can trust every time. Whether you’re building supports for power plant scrubbers or fasteners for industrial desulfurization systems, this bar’s ready to perform. Got a unique spec in mind? Let us know, and we’ll make it happen.

About Us:

Our 12,000㎡ factory is equipped with complete capabilities for research, production, testing, and packaging. We strictly adhere to ISO 9001 standards in our production processes, with an annual output of 1,200 tons. This ensures that we meet both quantity and quality demands. Furthermore, all products undergo rigorous simulated environment testing including high temperature, high pressure, and corrosion tests before being dispatched, ensuring they meet customer specifications.

For all our clients, we offer timely and multilingual after-sales support and technical consulting, helping you resolve any issues swiftly and efficiently.

Client Visits

Building Stronger Partnerships

We support all kinds of testing:

FAQs:

1. What is Hastelloy C-276 bar made of?
   It’s a nickel-molybdenum-chromium alloy with about 57% nickel, 16% molybdenum, 16% chromium, plus tungsten and iron for corrosion resistance.

2. What are the main uses for Hastelloy C-276 bar in flue gas desulfurization?
   It’s used for scrubber supports, structural rods, and fasteners in desulfurization systems.

3. How does Hastelloy C-276 bar perform in corrosive environments?
   It’s a champ, resisting corrosion from sulfur compounds, acids, and chlorides in flue gas settings.

4. Can Hastelloy C-276 bar handle high temperatures?
   Yep, it’s stable up to 1093°C, perfect for scrubber supports in high-heat desulfurization systems.

5. Is Hastelloy C-276 bar cost-effective?
   It’s pricier than stainless steel, but its durability in harsh environments makes it a smart long-term choice.

6. How does Hastelloy C-276 bar compare to Hastelloy C-22 bar?
   C-276 excels in reducing acids and pitting resistance, while C-22 is better for oxidizing acid environments.

7. Can Hastelloy C-276 bar be customized?
   Totally! We can adjust diameter, length, or finish to meet your specific scrubber support needs.

8. Is Hastelloy C-276 bar environmentally friendly?
   It’s recyclable, supporting green practices, and its long lifespan reduces waste from replacements.
