Hastelloy B3 Wire for Acid Production Unit Structural Supports
Our Hastelloy B3 wire is a total rockstar for acid production unit structural supports, built to handle the harshest chemical environments without batting an eye. This nickel-molybdenum alloy, with about 65% nickel, 28% molybdenum, and a pinch of chromium, iron, and cobalt, is our go-to for applications where corrosion resistance and strength are non-negotiable. Whether it’s structural supports, mesh reinforcements, or springs in acid production equipment, this wire keeps your systems solid and reliable.
What makes Hastelloy B3 wire stand out is its killer ability to resist corrosion in strong acids like hydrochloric and sulfuric, as well as other reducing acids. It’s perfect for structural supports in acid production units, shrugging off pitting, crevice corrosion, and stress corrosion cracking to keep your equipment standing strong with minimal maintenance. This wire ensures your production stays safe and efficient, no matter how brutal the conditions get.
Comparison Parameters Table
Parameter | Hastelloy B3 Wire | Hastelloy B2 Wire | Stainless Steel 316 Wire | Monel 400 Wire |
|---|---|---|---|---|
Corrosion Resistance | Excellent (HCl, sulfuric acid) | Excellent, slightly less stable | Good, weaker in strong acids | Excellent, less effective in HCl |
Electrical Conductivity | Low (~1.5% IACS) | Low (~1.5% IACS) | Low (~2% IACS) | Moderate (~3-4% IACS) |
Thermal Stability | High (up to 760°C) | High (up to 700°C) | High (up to 870°C) | Moderate (up to 550°C) |
Mechanical Strength | High, good ductility | High, slightly less ductile | Very high, less ductile | Good, high ductility |
Formability | Moderate, easier than B2 | Moderate, harder to fabricate | Moderate, harder to form | Excellent, easy to shape and weave |
Cost | High, due to alloy complexity | High, similar to B3 | Moderate, lower than Hastelloy | High, lower than B3 |
Typical Applications | Acid unit supports, reactor springs | Acid processing, chemical linings | Marine fittings, chemical components | Marine connectors, desalination mesh |
Durability | Long lifespan, excellent in acids | Long, slightly less in pitting | Long, varies in acidic environments | Very long, less in strong acids |
This wire’s versatility is a huge win. It’s stable up to 760°C, which is plenty for acid production units operating in moderate-heat environments, like those in chemical plants or fertilizer facilities. Its low electrical conductivity (~1.5% IACS) is great for applications where electrical isolation matters, and its high strength means it can take on mechanical stress without cracking. From sulfuric acid plants to pharmaceutical processing, Hastelloy B3 delivers.
We love how workable this wire is, especially compared to other high-performance alloys. Its improved fabrication stability makes it easier to form, weave, or weld into whatever your structural support design needs—think robust supports or fine mesh reinforcements. Need a specific diameter, strength, or finish? We can tailor it to fit your specs, keeping your fabrication smooth and your project on schedule.
The acid production industry’s all about materials that are tough, efficient, and sustainable, and Hastelloy B3 wire nails it. It’s recyclable, which is awesome for eco-friendly projects, and its long lifespan means less waste from replacements. With global demand for acids, fertilizers, and pharmaceuticals growing—think green chemistry and battery production—Hastelloy B3’s acid resistance is more critical than ever. Its low maintenance aligns with the push for cost-effective, sustainable operations.
Specification
item | HC-276 | C-22 | C-4 | B2 | B3 | N |
C | ≤0.01 | ≤0.015 | ≤0.015 | ≤0.02 | ≤0.01 | 0.04-0.08 |
Mn | ≤1 | ≤0.5 | ≤1 | ≤1 | ≤3 | ≤1 |
Fe | 4-7 | 2-6 | ≤3 | ≤2 | ≤1.5 | ≤5 |
P | ≤0.04 | ≤0.02 | ≤0.04 | ≤0.04 | -- | ≤0.015 |
S | ≤0.03 | ≤0.02 | ≤0.03 | ≤0.03 | -- | ≤0.02 |
Si | ≤0.08 | ≤0.08 | ≤0.08 | ≤0.1 | ≤0.1 | ≤1 |
Ni | rest | rest | rest | rest | ≤65 | rest |
Co | ≤2.5 | ≤2.5 | ≤2 | ≤1 | ≤3 | ≤0.2 |
Ti+Cu | -- | -- | ≤0.7 | -- | ≤0.4 | ≤0.35 |
Al+Ti | -- | -- | -- | -- | ≤0.5 | ≤0.5 |
Cr | 14.5-16.5 | 20-22.5 | 14-18 | ≤1 | ≤1.5 | 6-8 |
Mo | 15-17 | 12.5-14.5 | 14-17 | 26-30 | ≤28.5 | 15-18 |
B | -- | -- | -- | -- | -- | ≤0.01 |
W | 3-4.5 | 2.5-3.5 | -- | -- | ≤3 | ≤0.5 |
V | ≤0.35 | ≤0.35 | -- | 0.2-0.4 | -- | ≤0.5 |
Shape | Size (mm) |
Wire | 0.5-7.5 |
Rod/Bar | 8.0-200 |
Strip | (0.5-2.5)*(5-180) |
Tube/Pipe | Custom made |
Sheet/Plate | Custom made |
For more details, pls directly contact us.
Our Hastelloy B3 wire sets the bar high because we’re all about quality, customization, and customer success. We offer a wide range of diameters, strengths, and finishes, with fast delivery for both small and large orders. Our team dives deep into your project, optimizing the wire for your acid production unit supports to ensure maximum corrosion resistance and durability. We keep pricing competitive, especially for bulk orders, without skimping on quality. Our sustainable production process uses recyclable materials, aligning with green industry trends. Plus, our hands-on support means you’re always covered—whether it’s technical guidance or a custom solution, we make it happen.
Compared to other materials, our Hastelloy B3 wire is a clear standout. Hastelloy B2 is solid for acid resistance but less stable during fabrication and more prone to pitting. Stainless steel 316 is tough but falters in strong acid environments, unlike B3. Monel 400 is corrosion-resistant but doesn’t match B3’s performance in hydrochloric acid settings. Our wire is the ultimate choice for acid production unit structural supports.
We craft our Hastelloy B3 wire to meet strict standards like ISO 9001, ensuring quality you can bank on every time. Whether you’re building supports for acid reactors or springs for chemical equipment, this wire’s ready to perform. Got a unique spec in mind? Let us know, and we’ll make it happen.
About Us:
Our 12,000㎡ factory is equipped with complete capabilities for research, production, testing, and packaging. We strictly adhere to ISO 9001 standards in our production processes, with an annual output of 1,200 tons. This ensures that we meet both quantity and quality demands. Furthermore, all products undergo rigorous simulated environment testing including high temperature, high pressure, and corrosion tests before being dispatched, ensuring they meet customer specifications. We also provide chemical analysis reports for every FeCrAl alloy, NiCr alloy, and other products purchased.
For all our clients, we offer timely and multilingual after-sales support and technical consulting, helping you resolve any issues swiftly and efficiently.
Client Visits
Building Stronger Partnerships
We support all kinds of testing:
FAQs:
What is Hastelloy B3 wire made of?
It’s a nickel-molybdenum alloy with about 65% nickel, 28% molybdenum, plus small amounts of chromium, iron, and cobalt for corrosion resistance.What are the main uses for Hastelloy B3 wire in acid production units?
It’s used for structural supports, mesh reinforcements, and springs in equipment handling acids like hydrochloric and sulfuric.How does Hastelloy B3 wire perform in acid environments?
It’s a beast, resisting corrosion, pitting, and stress corrosion cracking in strong acid conditions.Can Hastelloy B3 wire handle high temperatures?
Yep, it’s stable up to 760°C, great for acid production unit supports in moderate-heat settings.Is Hastelloy B3 wire cost-effective?
It’s pricier than stainless steel, but its durability in acidic environments makes it a smart long-term choice.How does Hastelloy B3 wire compare to Hastelloy B2 wire?
B3 has better thermal stability and fabrication ease, while B2 is slightly less resistant to pitting.Can Hastelloy B3 wire be customized?
Totally! We can adjust diameter, strength, or finish to meet your specific structural support needs.Is Hastelloy B3 wire environmentally friendly?
It’s recyclable, supporting green practices, and its long lifespan reduces waste from replacements.
